Inspired Flights GS-ONE Ground Control Station | All-in-One NDAA-Compliant GSC
The GS-ONE is Inspired Flight’s next-generation handheld ground control station, purpose-built for mission-critical performance in the field. Designed for the IF800 Tomcat and IF1200 platforms, GS-ONE gives operators an intuitive, high-visibility interface and powerful command over every mission.
With a glove-compatible 7” touchscreen rated at 2000 NIT brightness, GS-ONE delivers a sunlight-readable experience in any environment. Pilots receive real-time video, telemetry, and aircraft control through a built-in 2.4 GHz NDAA-compliant radio, offering up to 6 miles of range. Cellular LTE, WiFi 6, and Bluetooth 5.2 ensure reliable connectivity wherever your mission takes you.
Engineered for long days in the field, the GS-ONE includes tool-less hot-swappable batteries offering up to 5 hours of runtime per pack. Running Android 14 and powered by a Qualcomm QCS6490 processor, GS-ONE features 8 GB of RAM and 128 GB of internal storage, delivering responsive performance across Inspired Ground Control and third-party apps like UGCS or QGroundControl.
With an IP55 rating, programmable buttons, onboard GNSS, and versatile I/O (HDMI, Ethernet, USB, Micro SD, SIM), the GS-ONE empowers pilots with the confidence and control needed for demanding commercial, utility, and public safety operations.
Inspired Flight GS-ONE | Built for the Field, Ready for the Future
Compatibility
IF800 TOMCAT: Not Retrofit-Compatible
Due to earlier design specifications on the IF800 TOMCAT, retrofitting existing aircraft to support the GS-ONE is not possible. The radio hardware required for GS-ONE operation cannot be accommodated in legacy IF800 airframes.
What You Should Know:
- Only newly manufactured IF800s are built with an internal structure that supports a GS-ONE radio configuration. Customers interested in using the GS-ONE with the IF800 will need to purchase a newly configured IF800 unit.
IF1200A: Retrofit Available
The IF1200A can be retrofitted to support the GS-ONE. While this retrofit is possible, it requires specific hardware integration and setup that may vary depending on the system.
What You Should Know:
- Retrofitting the IF1200A is a custom service and will include hardware installation, firmware configuration, and radio pairing.
- Pricing, lead time, and installation logistics will depend on your current system and configuration.
In the Box
1 - Inspired Flight GS-ONE Ground Control Station
Specifications
General
-
Size: 29 x 18 x 8 cm (11.3 x 7.0 x 3.2 in)
-
Weight: 1.80 kg (3.9 lbs)
-
Display: 7” 1080P LCD, 2000 NIT brightness, touchscreen
-
Operating System: Android 14
-
Processor: Qualcomm QCS6490
-
Memory: 8 GB RAM, 128 GB storage
Battery & Power
-
Runtime: 4–5 hours
-
Battery Type: 2S 10,400mAh, hot-swappable
-
Charging: USB-C PD2.0, full charge in <3 hours
Connectivity
-
Cellular: 4G LTE, CAT 7
-
WiFi: 802.11 a/b/g/n/ac/ax (2.4GHz)
-
Bluetooth: v5.2
-
Radio: NDAA Complaint 2.4 GHz, up to 6.2 miles range
I/O & Interfaces
- USB-A 2.0, USB-C 2.0
- Full-size HDMI
- RJ-45 Ethernet
- 3.5mm Audio Jack
- SIM Card Slot
- Micro SD (UHS-1 Grade 3)
GNSS Support
- GPS, GLONASS, Galileo, QZSS, SBAS
Environmental
-
IP Rating: IP55
-
Operating Temp: 0°C to 45°C (32°F to 113°F)
